Ilsintech SWIFT KR12A ALL-IN-ONE Ribbon Fusion Splicer
Introducing the new Swift KR12A All-In-One Ribbon Splicer. This premium fusion splicer offers a strong option for in-field fiber splices that delivers superior optical performance and improved productivity. Integrated with 5 functions in one unit, the KR12A can strip, clean, cleave, splice and protect in less time and with better results. In addition the rotating blade life can handle up to 3,650 fibers and unit maintenance can be achieved through an online connection.

Ilsintech SWIFT KR12A ALL-IN-ONE Ribbon Fusion Splicer

$12,525.00Price
Quantity

  • All-In-One Ribbon Fusion Fiber Splicer Kit
    Kit Inludes:
    *Swift KR12A Splicer Main Body
    *Carrying Case
    *H7-12, 12 Ribbon Fiber Holders
    *6000mAh Battery
    *S311, AC Adapter
    *S312, Sleeve Loader (2)
    *EI-28, Electrodes
    *CT-03, Cooling Tray
    *Alcohol Dispenser

  • :

    Category Description
    Fiber alignment

    Ribbon
    Applicable type of fibers

    SM (G.652); MM (G.651); DS (G.653); NZDS (G.655)
    Fiber count

    Single fiber; 2-12 ribbon fiber
    Applicable fiber dimensions

    Single: Cladding diameter: 125㎛; Coating diameter 250: 900㎛

    Ribbon: Cladding diameter: 125㎛; Ribbon fiber thickness 0.25 to 0.40mm
    Fiber setting and cleaved length

    10mm
    Splicing modes

    Splice mode: 300, Heat mode: 100; Strip mode: 50
    Typical splice loss

    SM: 0.05dB, MM: 0.02dB, DS: 0.08dB, NZDS: 0.08dB
    Return loss

    > 60dB (typical)
    Splicing time

    Typical 20 sec. with standard SM (ITU-T G.652)
    Sleeve heating time

    1~2 core 20 sec.; 4-12 core 50 sec.
    Applicable protection sleeve

    40mm, 60mm (fiber)
    Storage of splice result

    The last 10,000 results to be stored in the internal memory (image 10,000 results)
    Tension test

    2N/4.4N (option)
    Operating condition

    Altitude: 0-3,660m above sea level, Temperature: -10ºC ~ 50ºC (-14ºF ~ 122ºF); Humidity: 0~95%;

    Wind: 15m/s, non-condensing, dust proof, water proof, shock proof
    Storage condition

    Temperature: -40ºC~ 80ºC (40ºF ~ 176ºC); Humidity: 0~95%
    Dimension

    136(W) x 215(L) x 132(H) mm (excluding bumper)
    Weight

    2.3kg (including battery)
    Viewing method and display

    Two CMOS cameras and 127mm (5.0 in) color LCD monitor with electrostatic touch screen
    Fiber view and magnification

    X/Y: 20X; Max: 60X
    Power supply

    100~240V AC
    No. of splice cycles with battery

    Typical 236 cycles (6000mAh)
    Electrode life

    Up to 1,500 splices
    Terminals

    USB, external power (DC 12V (available for car cigar jack)); DC output 13.2-16.8V
    Blade life

    Up to 3,650 cleaves
